Product Details
Core Points
Transit-Specific Precision
o Direct bolt-on replacement for 2014-2023 Transit high-mount brake light positions.
o Compatibility: Short/Long Wheelbase, 12V Gasoline & 24V Diesel variants.
Warehouse-Ready Visibility
o Sony IMX307 Sensor: 1080P@30fps with 6 IR LEDs (5m illumination range).
o 170° Coverage: 130° horizontal view for dockyard maneuvers.
Heavy-Duty Construction
IP68 Protection: Triple-sealed aluminum housing (-30℃~85℃ operation).
10G Shockproof: Validated for 300,000km commercial service life.
Technical Specifications
|
Parameter |
Specification |
|
Resolution |
1920×1080@30fps (AHD 1080P) |
|
Viewing Angle |
170° diagonal / 130° horizontal |
|
Waterproof Rating |
IP68 (1m/30min immersion) |
|
Operating Voltage |
DC12V/24V (customizable) |
|
Video Output |
CVBS/AHD via RCA/aviation connectors |
Vehicle Compatibility List
• Ford Transit T-Series: 2014-2023
o T-150/T-250/T-350 (Gasoline)
o T-250HD/T-350HD (24V Diesel)
o Cargo Van/Passenger Wagon
User Pain Point Solutions
- Blind Spot Hazards → 170° coverage + dynamic guidelines.
- Waterproof Failure → IP68 triple sealing prevents electrical shorts.
- Complex Retrofits → 10-minute installation via pre-terminated harness.
Product images
