Product Details

Key Points

Short Wheelbase-Specific Design

Precision-molded for C7 platform short-wheelbase A6L (2912mm), replicating OEM handle curvature (±0.1mm tolerance).

Sony Dual Night Vision Engine

IMX335 Starlight Sensor + 6-layer glass lens (F1.6 aperture) enables full-color imaging at 0.001Lux without ambient light.

Tool-Free Quick Installation

15-minute direct replacement using factory screw holes, preserving anti-theft studs. Zero wiring modifications required.

Military-Grade Resilience

IP69K waterproof/dustproof housing + dual-shielded anti-interference cabling. Stable operation from -40℃ to 105℃.

Technical Specifications

Parameter	Specification
Compatibility	Audi A6L C7 Short Wheelbase (2012-2018, 2912mm)
Installation	Left/right OEM short handle position (supports power-assisted handles)
Signal Protocol	AHD 1080P@30fps + CVBS 650TVL
Optical Lens	6-layer all-glass lens (F1.6 aperture)
Night Vision System	Sony IMX335 Starlight Sensor
Dynamic Trajectory	Steering angle + speed + short-wheelbase compensation algorithm
Water & Dust Proof	IP69K (withstands 100Bar pressure wash)
