Key Highlights

• Multi-Signal Compatibility: CVBS analog (pre-2018 models) / Digital HD (post-2018 models)
• IP68-rated durability with anti-corrosion connectors
• Vehicle group-specific engineering: Adjustable angles (SUVs/MPVs) vs. ultra-slim designs (sedans)

Product Details

Technical Specifications

Parameter	Description
Compatibility	SUV Series: GLA/GLC/GLE/GLB (2015-2024) Sedan Series: A/B/C-Class (2013-2024) MPV Series: V-Class/Metris (2016-2024)
Signal Type	Digital HD (2018+ models) / CVBS analog + decoder (pre-2018)
Resolution	1920×1080 (Digital) / 1280×720 (CVBS)
Viewing Angle	170° ultra-wide (SUVs/MPVs) / 150° (sedans)
Installation	License lamp replacement (SUVs) Logo-integrated/slim bracket (sedans)
Special Features	±10° vertical tilt (SUVs/MPVs) 1.5cm thickness (sedans)
Warranty	12-month camera coverage

Vehicle Group-Specific Engineering

A. SUV Series (GLA/GLC/GLE/GLB)
• Problem Solved: High ground clearance obscures low obstacles (curbs, toys)
• Solution:
▶ Manual vertical tilt adjustment displays 30cm below rear bumper
▶ Reinforced bracket withstands off-road vibrations

B. Sedan Series (A/B/C-Class)
• Problem Solved: Discreet installation preserving factory aesthetics
• Solution:
▶ A/B-Class: License lamp replacement (retains right-side lighting)
▶ C-Class: OEM emblem replacement (custom CNC-machined bracket)
▶ 1.2cm ultra-thin profile withstands car wash pressure

C. MPV Series (V-Class/Metris)
• Problem Solved: Long-wheelbase rear monitoring challenges
• Solution:
▶ 5m coverage with tri-color grid (Green=2m/Yellow=1m/Red=0.5m)
▶ Dual-camera PIP (picture-in-picture) support via decoder

Signal Generation & Protocol Sync

Model Year	Transmission Method	Key Features
Pre-2018	CVBS + GL-Series Decoder	• Syncs parking radar/door status • Anti-flicker voltage stabilization
2018+	Digital Direct (HDMI/FAKRA)	• Retains touchscreen gestures • Plug-and-play installation

Installation Advantages

Traditional Retrofit	Our Solution
Requires screen replacement	Preserves factory head unit
Wiring modifications needed	100% plug-and-play T-harness
Fixed camera angles	Pre-calibrated per vehicle group

Package Options

Kit Type	Components	Application Scope
Basic	Camera + vehicle-specific bracket	Users with existing decoder
Advanced	Camera + decoder + calibration tools	Full protocol integration
MPV Expansion	Dual cameras + splitter	Commercial vehicle fleets

Critical Notes

Post-2018 digital models require screen resolution verification (minimum 1280×720)
4K camera upgrade available for 2020+ models with HDMI-compatible screens
