Key Highlights
• Dynamic trajectory steering sync (C-Class exclusive)
• Ultra-slim 1cm profile for CLA coupe logo integration
• Dual-signal compatibility: Digital HD (post-2018) / CVBS analog + decoder
Product Details
Technical Specifications
|
Parameter |
C-Class (W205) |
CLA Series (C117/X117) |
|
Compatibility |
2015-2021 (incl. facelifts) |
2015-2019 (Coupe/Shooting Brake) |
|
Signal Type |
Digital (2018+) / CVBS+NTG5 decoder (pre-2018) |
CVBS analog + CLA-specific decoder |
|
Resolution |
1920×1080 (Digital) / 1280×720 (CVBS) |
1280×720 |
|
Viewing Angle |
160° wide-angle |
150° low-profile optimized |
|
Installation |
License lamp replacement |
Logo integration (Coupe) / Trunk handle (SB) |
|
Guidance System |
Steering-linked dynamic trajectory |
Fixed grid lines |
|
Waterproof Rating |
IP68-rated |
Chrome anti-corrosion housing |
|
Warranty |
1-year camera coverage |
1-year decoder warranty |
Core Functionality
A. Dual-Signal Intelligence
• Post-2018 C-Class: Direct digital feed to NTG5.1 head unit:
▶ Zero latency with touchscreen/CarPlay compatibility
• Pre-2018/CLA Series: CVBS decoder bypasses OEM restrictions:
▶ Preserves factory UI fonts/color schemes
B. Coupe-Specific Engineering
• CLA Shooting Brake: Trunk handle replacement matches curvature within ±0.5mm
• CLA Coupe: Logo-integrated camera maintains frameless door aesthetics:
▶ 6063-T6 aluminum bracket withstands 200N lateral force
C. Signal Integrity Assurance
• Quad-shielded RG174 coaxial cable (Digital):
▶ 90dB EMI suppression at 2.4GHz
• CVBS signal booster with automatic gain control
Installation Protocols
|
Model |
Challenge |
Technical Resolution |
|
CLA Coupe |
No factory camera provisions |
Custom logo bracket + hinge conduit routing |
|
C-Class Pre-FL |
Screen video input lockdown |
NTG5 decoder with CAN protocol emulation |
|
CLA Shooting Brake |
Complex trunk curvature |
Pressure-sensitive 3M VHB tape installation |
Package Options
|
Kit Type |
Components |
Application Scope |
|
C-Class Digital Direct |
HD Camera + FAKRA cable |
2018+ W205 models |
|
CLA Ultimate |
Logo camera + decoder + hinge kit |
CLA Coupe/Shooting Brake |
|
Classic CVBS Bundle |
Camera + NTG5 decoder + OBD splitter |
Pre-2018 C-Class/CLA |
Critical Notes
1. Dynamic trajectory requires CAN-H/CAN-L connection to steering column module (harness included)
2. CLA logo cameras pre-calibrated at 12° downward tilt for optimal coupe visibility
FAQ
Q: Will this work on my 2016 CLA 45 AMG with OEM parking sensors?
A: Yes. The system operates in parallel without affecting existing sensor alerts.
Q: How to maintain rear logo illumination on CLA?
A: The integrated camera preserves original LED backlighting at 5000K color temperature.
Q: Compatibility with right-hand-drive C-Class?
A: Full compatibility. License lamp replacement switches to left side for RHD markets.
